Nautical Chart E1 - Azores Archipelago | Imray - 1:750,000

The Imray E1 nautical chart covers the whole Azores archipelago in the North Atlantic, from Flores and Corvo in the west to Santa Maria in the east. A classic stopover on transatlantic passages, the archipelago is covered with ten plans of its main harbours.

This edition includes the latest official bathymetric surveys, the completed harbour works at Velas (São Jorge) and additional marine reserves; magnetic variation curves have been added and the chart has been generally updated.

Coverage

• Western group: Flores and Corvo
• Central group: Faial, Pico, São Jorge, Graciosa and Terceira
• Eastern group: São Miguel and Santa Maria

Detailed plans included

• Lajes das Flores (Flores) – 1:20,000
• Horta (Faial) – 1:12,500
• Lajes do Pico (Pico) – 1:10,000
• Velas (São Jorge) – 1:7,500
• Vila da Praia (Graciosa) – 1:10,000
• Praia da Vitória (Terceira) – 1:20,000
• Angra do Heroísmo (Terceira) – 1:12,500
• Ponta Delgada (São Miguel) – 1:10,000
• Vila Franco do Campo (São Miguel) – 1:15,000
• Vila do Porto (Santa Maria) – 1:10,000

Features

• Main scale: 1:750,000
• Type: passage chart
• Unfolded size: 64 x 90 cm, folded to A4 in a plastic wallet
• Water-resistant Pretex paper
• Language: English

Imray-Iolaire series – Atlantic islands

Imray-Iolaire charts of the Atlantic islands combine the latest official hydrographic data with first-hand observations gathered over more than 60 years by Don Street Jr and his network of contributors. They show many anchorages, facilities and passages not found on official charts.

Like all Imray charts, they are printed on water-resistant Pretex paper, designed for heavy use on board.

Updates and corrections

Nautical information changes: Imray regularly publishes corrections, available free of charge on its website. On recent editions, a QR code printed on the chart gives direct access to these updates and any supplements.
